Specifications
JIS G 3312 CGCC, CGCH, CGCD,CGC(340/400/440/490/570)
JIS G 3318 CZACC, CZACH,CZACD, CZAC(340/400/440/490/570)
ASTM A 755, ASTM A 924
Suitable for white electronics, building materials, public utilities, whiteboards, refrigerator and vehicles,
Dimensions
| Thickness(mm) | Width(mm) | Length(mm) | Coil I.D.(mm) | Coil Weight |
|---|---|---|---|---|
| 0.23-1.60 | 1270 Max | 600-5,000 | 508-610 | 15MT Max |
Characteristics
| Raw Materials | Specification | Characteristics |
|---|---|---|
| Cold Rolled Steel | ASTM A-366 JIS G 3141 | Excellent Formability, Excellent Weldability, Excellent Surface, Bright Surface |
| Hot Dip Galvanized Steel | ASTM A-526 JIS G 3302 | Corrosion Resistance |
| Electrolytic Galvanized Steel | ASTM A-591 JIS G 3313 | Excellent Formability |
| Galvannealed Steel | ASTM A-526 JIS G 3302 | Good Weldability Corrosion Resistance |
| Aluminized Steel | ASTM A-463 JIS G 3314 | Corrosion Resistance |
| Black Plate | ASTM A-623 JIS G 3303 | Heat Reflectiveness Excellent Workability |
| Aluminum Steel | ASTM B-209 JIS G 4000 | Heat Resistance High Durability |
| Stainless Steel | ASTM A-895 JIS G 4305 | High Durability |
| Supergalum | ASTM A-792 EN 10215 | Chemical Resistance, Corrosion Resistance, Heat Reflectiveness, High Durability |
- R.M.P(Regular Modified Polyester) : for free fabricated house
- H.D.P(High Durability Polyester) : for corrosion resistance
- P.V.D.F(Poly Vinylidyne Fluoride) : guarantee for min 20 years
- H.P.P(High Polymer Polyester) : for workability and beauty
- P.S.S(Printed Steel Sheet) : for steel furniture, home appliances,
Standard Packing
Special care is given to prevent abrasion, rust and scratch during transportation and shipment, the procedures are illustrated as follows.
Unit weight is usually 2-5mt for sheet, 4-20mt for coils upon to the request.
